ATL Braketesters

UK Mot Approved

TEN Class IV & VII

The Ten Braketester offers the latest in computer technology for Roller Brake Testing specifically where mandatory vehicle testing requires speed and precision. Supplied as a key option to the INNOVA 2000 Emissions Analyser the TEN Braketester will easily intergrate into the TEN test lane for the measurement of Sideslip, Suspension and Vehicle Speed as well as Brake Force.

The bi-directional rollers are epoxy coated and impregnated with a grit substrate for maximum resistance when tyres are wet. The robust chassis is completely galvanic and corrosion resistant. Each roller is fitted with seperate sensors for automatic 'test start' operation and to ensure the vehicle test is 'in position and continuious with the tyre during the brake test routine

All Ten Braketesters are available with 'Factory Fitted' ATL option

BTL67 Class IV -Compact single chassis for vehicles up to 4 tonne.
BTL60VB Class VII -Compact singe chassis for vehicles up to 5.2 tonne.

Technical Specifications:	BTL67	BTL60VB
Test width min. (mm)	800	800
Test width max. (mm)	2200	2600
Max. Axle weight (tonne)	4	5,2
Motor Power (k Watt)	2 x 4kW	2 x 4 kW
Mains Voltage (3 Phase)	380V/50Hz	380V/50Hz
Test speed Km/h	5	5
Display	Monitor (INNOVA2000 PC Presentation)	Monitor (INNOVA2000 PC Presentation)
Roller diameter (mm)	200	200
Roller coating (Gritted)	epoxy	epoxy
Connection to PC (RS 232)	serial	serial
Connection Cable length (m)	15	15

This Website is subject to alteration or withdrawl without notice. Illustrations and specifications are not binding in detail.
